Applications: Universal air filter element

Filter Type: Cone

Dimensions:
Flange Inside Diameter (A) 78mm
Flange Outside Diameter (B) 81mm
Base Outside Diameter (C) 149mm
Flange Length (D) 44mm
Filter Length (E) 152mm
Total Length (F) 196mm
Top Diameter (G) 114mm

Manufacturer's Part Number: JC60/78FC

Maxogen

This is the original design of maxogen filter that dates back to the late 1980s. These JC60 filters are reinforced with open pore internals. This allows the filters to be squashed down and manipulated to allow them to be fitted in spaces where there is restricted access. As they do not have a reinforced plastic cage these are not recommended for turbo applications. It is without doubt the lightest filter of this kind on the market.
